| Type | Reconfigurable device | None |
Power supply range | 1.8-5.5V | None |
| General-purpose input/output | 6 | Support multi-level input, built-in pull-up and pull-down resistors; open-drain or push-pull outputs, optional driving capability of 10mA/20mA/40mA |
Digital combination unit | 8 pcs | Configurable logic, edge detection, pipeline delay, graphic generation, and trigger |
Multifunctional unit | 7 pcs | For counter, delay, one-shot, frequency detection, etc. |
| Clock | 2Mhz | Built-in multiple dividers, 3uA power consumption |
| I2C interface | 1 pcs | I2C slave device, up to 1Msps |
| Temp. range | -40 - 85℃ | Standard industrial grade |
| Package | TQFN8 | Size 1.3mm *1.3mm |
| DFN8 | Size 2.0mm *2.0mm |
