Model | LSS10031T | Description |
Type | Standard device | Reset and level conversion |
Power supply range | 2.3V -5.5V | None |
Static current | 3uA | None |
Voltage monitoring | 2.9V | Reset time 200mS |
Watchdog | 80 s | Refreshing on rising edge, both reset and voltage monitoring share the same pin |
Level conversion | 2 Channels | From low power rail to high power rail |
Level conversion | 2 Channels | From high power rail to low power rail |
Temp. range | -40 - 85 degrees | Industrial grade |
Package | TQFN14 | Size 1.6mm * 2.0mm |
